Unmanned Aerial Complex "Berkut-3E"

Unmanned Aerial Complex "Berkut-3E"
Unmanned Aerial Complex "Berkut-3E"
Purpose / Description

The system is used to solve tasks on optical and electronic reconnaissance in the visible range of the electromagnetic spectrum and (or) meteorological reconnaissance

Basic features

Practical ceiling

not less 3 000 m

Operating range

not less 50 km

Flight time

not less 3 h

Indicated level flight speed

up to 60 до 100 km/h

Takeoff

elastic catapult

Landing

parachute with sling cut-off system

UAV weight

not more 16 kg

Power plant type

pulling propeller motor

Preparation time for the start

not more 15 min

UAV size:


wing length

3570 mm

length

875 mm

height

253 mm

Root-mean-square error in determining the coordinates of a ground object X, Y

not more 50 m

Performed functions
  • Automatic flight mode (suitable to perform the flight in unattended mode in accordance with entered flight task, including landing);
  • automated flight mode (under control and on operator’s commands);
  • real-time color video transfering to the ground control station;
  • real-time black-and-wight picture transfering in the infrared range to the ground control station;
  • real-time meteorological data transfering to the ground control station.
Maintenance and Diagnostics
  • The warranty period for the supplied equipment is 12 months
  • The product life cycle is at least 5 years since the date of commissioning
  • Video review
